Major specifications for AccurioLabel 230 (Printer main body only)
| Type |
Console |
| Print method | Dry-toner electrophotography |
| Color support | Full colour (CMYK) |
| Printing resolution/gradation | 3600 dpi (equivalent) × 1200 dpi / 8 bit |
| Printing image size | 90 × 115 to 320 × 1,195 mm |
| Paper width | 250 to 330.2 mm |
| Paper thickness range | 81 to 256 gsm (80 to 250 µm) |
| Print media | Non-tack paper (81 to 176 gsm) Tack paper (136 to 256 gsm) Tack coated paper G/M (136 to 256 gsm Tack Synthetic paper (136 to 176 gsm) Tack PP (136 to 176 gsm) Tack PET (136 to 216 gsm) |
| Print speed | Speed range |
Max.: 23.4 m/min. (76 fpm) High: 18.9 m/min. (62 fpm) Middle: 13.5 m/min. (44 fpm) Low: 9.45 m/min. (31 fpm) |
| By media | 81 to 176 gsm: Max. 23.4 m/min. 177 to 256 gsm: Max. 18.9 m/min. |
| Compatible file formats | PS, PDF (APPE supported), 8 bit TIFF |
| VDP file format | PPML, PDF-VT |
| Power source (Single phase) | Metric: 220 to 240 V 50/60 Hz, 25 A Inch: 208 to 240 V 60 Hz, 24 A |
| Max. power consumption | Metric: 6,000 W, Inch: 5,760 W |
| Dimensions (W × D × H) | 1,200 × 903 × 1,478 mm |
| Weight | 292 kg |
* Specifications and features of the delivered product are subject to changes.
Major Specifications for Unwinder/Winder unit DP330
| Maximum roll size |
Ø 600mm |
| Power requirements | 3 phase 380V, 20A, 50/60Hz |
| Print media | Paper: Tack paper, Non-tack paper Film: Tack film (Synthetic paper, PP, PET) , etc. |
| Dimensions (W × D × H) | 3,550 × 2,470 × 1,540 mm |
| Weight | Winding Unit: approx. 423kg Unwinding Unit: approx. 446 kg Platform: approx. 335 kg |
Specifications for embedded controller
| Type |
Embedded (AIO) type Equivalent to IC-605B with UK-104 |
| CPU | Intel Core i5 4570S 2.9 GHz (CPU in printer) |
| Memory | System Memory 16 GB |
| HDD | 1 TB × 3 + 500 GB × 1 |
| Network | 10/100/1000 Base-T |
| PDL Language | PostScript 3 (CPSI 3020), PDF Ver.1.7,TIFF Ver.6 Compliant, PPML Ver.2.2, PCL5c equivalent, PCL XL (PCL6 Ver.3) equivalent, APPE Ver.4.6*1, PDF/VT |
| Protocol | TCP/IP, NetBEUI, IPP, WSD, SMB, Bonjour |
| OS applicable | Windows 7, 8.1, 10 Windows Server 2008/R2, 2012/R2, 2016, 2019 (Includes 64 bit versions) Mac OS X 10.9, 10.10, 10.11, 10.12, 10.13, 10.14 |
| Main fonts |
Adobe 136 fonts, PCL 80 fonts |
| Driver | PS Plugin driver |
| Compatible file formats | PS, PDF (APPE supported), 8 bit TIFF |
| Konica Minolta applications applicable | PS Web Connection, PS Net care Device Manager, Color Centro, AccurioPro Hot Folder |
*1 UK-218 (Option) required
 |
 |
 |
Recommended hardware requirements
| Operating systems |
Windows 7/8.1/10 Pro (64bit) |
| Memory | 4 GB RAM |
| Disk space | 1 GB |
| CPU | Intel i5 dual core or equivalent |
| Screen resolution | 1,280 × 720 pixels |
 |
